Specifications

• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    34
  • Horsepower (kW):
    25
  • Horsepower RPM:
    9500
  • Torque (Ft Lbs):
    21
  • Torque (Nm):
    28
  • Torque RPM:
    7500
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (mm):
    80
  • Bore (in):
    3.15
  • Stroke (mm):
    62.1
  • Stroke (in):
    2.44
  • Displacement (cc):
    313
  • Displacement (ci):
    19.1
  • Turbocharged:
    No
  • Supercharged:
    No
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Premium
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Speed Governor:
    No
  • US Miles Per Gallon (Hwy):
    71
  • Fuel Injector Size (mm):
    42
  • Other Engine:
    Not Available
  • Compression ratio:
    10.6:1
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Chain
  • Gear Ratio (1):
    3
  • Gear Ratio (2):
    2.06
  • Gear Ratio (3):
    1.59
  • Gear Ratio (4):
    1.29
  • Gear Ratio (5):
    1.1
  • Gear Ratio (6):
    0.96
  • Reverse:
    No
  • Final Drive Ratio:
    3.08
  • Heel Toe Shifter:
    Not Available
  • Adjustable Throttle:
    Not Available
  • Primary Drive (Engine / Transmission):
    Gear
  • Other Transmission:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    81.8
  • Length (mm):
    2075
  • Width (in):
    34.7
  • Width (mm):
    880
  • Wheelbase (in):
    55.9
  • Wheelbase (mm):
    1420
  • Weight:
    Standard
  • Wet Weight (lbs):
    374
  • Wet Weight (kg):
    169.5
  • GVWR (lbs):
    761
  • GVWR (kgs):
    345
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    2.9
  • Fuel Capacity (l):
    11
  • Fuel Capacity Reserve (gal):
    0.3
  • Fuel Capacity Reserve (l):
    1
  • Performance:
    Standard
  • Payload Capacity (lbs):
    387
  • Payload Capacity (kgs):
    175.5
  • Height (in):
    48.5
  • Height (mm):
    1230
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Steel
  • Body Material:
    Plastic
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver and Passenger
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    No
  • Brush Guard:
    No
  • Chain Guard:
    Yes
  • Fork Guards:
    Yes
  • Light Guard:
    No
  • Exterior Covers:
    Standard
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Tank Divider:
    Not Available
  • Stand:
    Standard
  • Stand Type:
    Kick
  • Upper Fairing:
    Not Available
  • Lower Fairing:
    Not Available
  • Spoiler:
    Not Available
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Not Available
  • License Plate:
    Standard
  • Other Exterior:
    Not Available
  • Top Crown:
    Standard
  • Engine Case Guard:
    No
  • Chassis Protectors:
    No
  • Saddle Bag Guard:
    No
  • Radiator Cover:
    No
  • Drive Shaft Guard:
    No
  • Heel Guards:
    No
  • Fuel Tank Cover:
    No
  • Exhaust Guard:
    Yes
  • Tank Guard:
    No
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Inverted Fork
  • Front Travel (in):
    7.1
  • Front Travel (mm):
    180
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    7.1
  • Rear Travel (mm):
    180
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Other Suspension:
    Not Available
  • Rear Suspension Material:
    Aluminum
  • Front Suspension Size (in):
    1.6
  • Front Suspension Size (mm):
    41
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Front Wheel Width (in):
    2.5
  • Rear Wheel Width (in):
    4
  • Tires:
    Standard
  • Front Tire Width:
    110
  • Front Tire Aspect Ratio:
    80
  • Front Wheel Diameter:
    19
  • Rear Tire Width:
    150
  • Rear Tire Aspect Ratio:
    70
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    110/80 R19
  • Rear Tire (Full Spec):
    150/70 R17
  • Spare Tire:
    Not Available
  • Other Wheels & Tires:
    Not Available
  • Chromed:
    No
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    11.8
  • Front Brake Diameter (mm):
    300
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.5
  • Rear Brake Diameter (mm):
    240
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Other Brakes:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Not Available
  • Speakers:
    Not Available
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
  • Other Audio & Communication:
    Not Available
• COMMENTS

  add remove
  • Comment:
    Standard
  • Previous Model Year Accessories:
    Yes
