Specifications

• ENGINE

  add remove
  • Engine Type:
    745cc liquid-cooled 52° V-twin
  • Bore And Stroke:
    79mm x 76mm
  • Induction:
    PGM-FI with automatic enrichment circuit, one 34mm throttle body
  • Ignition:
    with 3-D mapping, two spark plugs per cylinder
  • Compression Ratio:
    9.6:1
  • Valve Train:
    SOHC; three valves per cylinder
  • Final Drive:
    Shaft
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    41mm fork; 4.6 inches of travel
  • Rear Suspension:
    Dual shocks with five-position spring-preload adjustability; 3.5 inches of travel
  • Front Brake:
    Single 296mm disc with twin-piston caliper
  • Rear Brake:
    Drum
  • Front Tire:
    120/90-17
  • Rear Tire:
    160/80-15
• Dimensions

  add remove
  • Rake:
    34°
  • Trail:
    161mm (6.3 inches)
  • Wheelbase:
    64.6 inches
  • Seat Height:
    25.8 inches
  • Curb Weight:
    549 pounds (Includes all standard equipment, required fluids and full tank of fuel ready to ride.)
  • Fuel Capacity:
    3.7 gallons, including 0.9-gallon reserve
  • Miles Per Gallon:
    56 MPG - Honda's fuel economy estimates are based on EPA exhaust emission measurement test procedures are intended comparison purposes only. Your actual mileage will vary depending on how you ride, how you maintain your vehicle, weather, road cond
• Other

  add remove
  • Emissions:
    Meets current EPA standards. California version meets current California Resources Board (CARB) standards and may differ slightly due to emissions equipment.
• Factory Warranty Information

  add remove
  • Warranty:
    Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
