Specifications

• ENGINE

  add remove
  • Engine Type:
    Liquid-cooled Unicam® four-stroke 22.5º parallel-twin
  • Bore And Stroke:
    92 mm x 81.5 mm
  • Compression Ratio:
    10.1:1
  • Valve Train:
    SOHC, Unicam, 4 valves per cylinder
  • Displacement:
    1,084 cc
  • Final Drive:
    #525 O-ring-sealed chain (16/42T)
  • Fuel Delivery:
    PGM-FI electronic fuel injection with 46 mm throttle bodies
  • Transmission:
    Six-speed Dual Clutch Transmission with four automatic shift modes and a manual mode
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    Electronically controlled Showa EERA™ 45mm inverted telescopic fork with spring preload, compression and rebound damping adjustability; 230 mm (9.1 in) travel
  • Rear Suspension:
    Pro-Link® system with electronically controlled Showa EERA™ with spring preload, compression and rebound damping adjustability, 220 mm (8.7 in) rear wheel travel
  • Front Brake:
    310 mm dual wave floating discs with aluminum hub and radial mount four-piston calipers and sintered metal pads
  • Rear Brake:
    256 mm wave disc with single-piston caliper and sintered metal pads. Lever-Lock Type Parking Brake System on DCT model with additional slide type single-piston caliper
  • Front Tire:
    90/90-R21 tubeless type
  • Rear Tire:
    150/70-R18 tubeless type
• Dimensions

  add remove
  • Wheelbase:
    1,575 mm (62 in.)
  • Seat Height:
    850 mm (33.5 in.) / 870 mm (34.3 in.)
  • Curb Weight:
    250 kg (551 lb) including required fluids and full tank of gas—ready to ride
  • Fuel Capacity:
    24.8 litres
